Rakata Motorcycle X5 vs Yamaha Nmax Comparison

Engine & Performance

Top Speed	50 kmph	--
Displacement	--	155 cc
Maximum Power	--	15 hp
No. Of Cylinder	--	1
Injection Type	--	Fuel Injection
Valve Configuration	--	SOHC
Drive Type	--	Belt Drive
Compression Ratio	--	10.5:1
Engine Type	--	Single Cylinder, 4-Stroke, Liquid Cooled SOHC VVA Engine
Lubrication System	--	Wet Sump
No. Of Strokes	--	4-Stroke
Cooling System	--	Liquid Cooled
Bore X Stroke	--	58 mm x 58.7 mm
Exhaust Pipes	--	Single Exhaust
Maximum Torque	--	13.9 Nm
Clutch Type	--	Single Dry Type
RPM at Maximum Power	--	8000 rpm
Fuel Tank Capacity	--	6.6 L
RPM at Maximum Torque	--	6000 rpm

View All

Dimension

Category	Scooter	Scooter
Seating Capacity	2 Seats	2 Seats
Height	1100 mm	1115 mm
Wheel Base	1270 mm	1350 mm
Width	650 mm	740 mm
Length	1720 mm	1955 mm
Oil Tank Capacity	--	0.9 L
Ground Clearance	--	124 mm
Kerb Weight	--	127 kg

View All

Fuel & Ignition

Start Option	Electric	Electric
Fuel Type	Electric	Petrol
Ignition System	--	TCI
Fuel Supply System	--	Fuel Injection

Gear & Transmission

Transmission Type

Automatic

CVT

Wheels & Tyres

Tyre Type	Tubeless	Radial, Tubeless
Front Tyre	3.0-10	110/70 R13
Front Wheel Size	10 Inch	R13
Rear Tyre	3.0-10	130/70 R13
Rear Wheel Size	10 Inch	R13

Chassis & Suspension

Front Suspension	Telescopic	Telescopic Fork
Rear Suspension	Dual Shock	Swing Arm

Electrical

Battery Capacity	20 Ah	--
Range City	70 km	--
Motor Type	Bosch	--

Safety & Security

ABS	--	No
Pass Switch	--	Yes
Engine Check Warning	--	Yes
Leg Guards	--	No
Launch Control	--	No
Traction Control	--	No
Wheel Lock Front/back	--	No
Back Rest	--	No
Side Reflectors	--	Yes
Riding Modes	--	Street Street

View All

Console

Odometer	Digital Digital	Digital Digital
Speedometer	Digital Digital	Digital Digital
Display Screen	Yes	Yes
Fuel Gauge	--	Digital Digital
Navigator	--	No
Side Stand Indicator	--	No
Tachometer	--	Yes
Tripmeter	--	Yes

View All

Electrical

Indicator Light	Yes	Yes
Adjustable Headlights	Yes	Yes
Head Lamp	LED LED	LED LED
Battery Voltage	60 V 60 V	12 V 12 V
Accessory Outlet	--	Yes
Tail Lamp	--	LED LED

View All

Brake

Front Brake	Discs Discs	Disc Disc
Rear Brake	Discs Discs	Disc Disc

Chassis & Suspension

Body Frame Type	--	Underbone Underbone
Side Wings	--	Yes
Electronic Suspension Adjustment	--	No
Seat Type	--	Dual Stepped Dual Stepped

Differentiating Features

Height Adjustable Seats	--	No
Cruise Control	--	No
